Product Summary
The CVM100BB160 is an IGBT Module. The applications of the device include Inverters for AC motors, Power supply units for DCmotors, DC power supply uints for battery chargers and General purpose DC power supply uints.
Parametrics
CVM100BB160 absolute maximum ratings: (1)The CVM100BB160 power Module package:IGBT ; (2)D/C:08+ ; (3)Brand: SanRex ; (4)Package / Case:VSO-56; (5)Maximum Clock Frequency:400 KHz; (6)Operating Supply Voltage:8.50V; (7)Maximum Supply Current:0.12 mA; (8)Maximum Power Dissipation:400 mW; (9)Maximum Operating Temperature:+ 180℃; (10)Minimum Operating Temperature:- 80℃.
Features
CVM100BB160 features: (1)All the terminals and the mounting plate are electrically isolated.These modules can be installed in the same cooling fin as other modules, thus saving installation space-a cost-effective feature; (2)The diode chips are coated with a glass of zinc oxide, making them highly resistent temperature and humidity variation; (3)6 diode chips are connected to the 3-phase bridge rectifying circuit inside the module-a cost-effective feature.
 |
