Product Summary

The 2DI150Z-120 is a kind of power transistor module. It is intended for power switching, AC motor controls, DC motor controls and uninterruptible power supply. It is insulated type. It include free wheeling diode. It features high voltage and excellent safe operating area. It is compatible with UL standard. The case is M210.

Parametrics

Absolute maximum ratings: (1)collector-base voltage, VCBO: 1200 V; (2)collector-emitter voltage, VCEO: 1200 V; (3)emitter-base voltage, VEBO: 10 V; (4)collector current: DC, IC: 150 A; 1 ms, ICP: 300 A; (5)base current: DC, IB: 8 A; 1 ms, IBP: 16 A; (6)collector dissipation: one transistor, PC: 1000 W; two transistors, PC: 2000 W; (7)junction temperature, Tj: +150℃; (8)storage temperature, Tstg: -40 to +125℃.

Features

Features: (1)high voltage; (2)including free wheeling diode; (3)excellent safe operating area; (4)insulate type.

Diagrams

2DI150M-120
2DI150M-120

Other


Data Sheet

Negotiable
