DMF5001NY-LY-ATE-BBN

LCD Module, -0.3 to 7.0V, LED Backlight / Yellow-green, 8-bit parallel data transfer

Rated 5 Rating 5 | reviews | Write a review

Price:: US $10.00~20.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $10.00~20.00

PartNumber:: DMF5001NY-LY-ATE-BBN

Brand:: OPTREX CORPORATION - ODC | Pack: DIP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Huang's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-07-08

From Other Seller

Part Number:DMF5001NY-LY-ATE-BBN
US $10.00 - 20.00
LM64P101

US $240.00 - 300.00 / Piece
(0) Remove
AT25256AW-10SU-2.7

US $0.65 - 1.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The DMF5001NY-LY-ATE-BBN is a LCD Module.

Parametrics

DMF5001NY-LY-ATE-BBN absolute maximum ratings: (1)Supply Voltage(Logic)VCC-VSS: min=-0.3V, max=7.0V; (2)Supply Voltage(LCD Drive)VCC-VEE: min=-0.3V, max=30.0V; (3)Input Voltage VI: min=-0.3V, max=VCC+0.3V.

Features

DMF5001NY-LY-ATE-BBN specifications: (1)Operating Temp：min. 0℃ ～ max. 50℃; (2)Storage Temp：min. -20℃ ～ max. 60℃; (3)Dot Pixels：160 (W) × 128 (H) dots; (4)Dot Size：0.54 (W) × 0.54 (H) mm; (5)Dot Pitch：0.58 (W) × 0.58 (H) mm; (6)Viewing Area：101.0 (W) × 82.0 (H) mm; (7)Outline Dimensions：129.0 (W) × 102.0 (H) × 19.2 max. (D) mm; (8)Weight：190g max.
