Product Summary
The LTM08C343S is a kind of 21cm COLOUR TFT-LCD MODULE. The mechnical specifications are as follows: (1)Dimensional Outline (Typ.): 201.4(W) x 140.3(H) x 5.8max(D) mm; (2)Number of Pixels: 800 (W) x 600 (H) pixels; (3)Active Area: 170.4(W) x 127.8 (H) mm; (4)Pixel Pitch: 0.213(W) x 0.213 (H); (5)Weight (approximately): 190g; (6)Backlight: Single CCFL, Sidelight type.
Parametrics
Absolute maximum ratigs: (1)Supply Voltage (VDD): -0.3 to 4.5 V; (2)Supply Voltage (VFL): 0 to 2.0 kV(rms); (3)FL Driving Frequency (fFL): 100 kHz max; (4)Input Signal Voltage (VIN): -0.3 to VDD+0.3 V; (5)Operating Temperature: 0 to 50℃; (6)Storage Temperature: -20 to 60℃; (7)Storage Humidity (Max. wet bulb temp. = 39℃): 10% to 90% (RH).
Electrical specifications: (1)Supply Voltage (VDD): 3.0 V min, 3.3 V typ and 3.6 V max; (2)Supply Voltage (VFL): 425 V(rms) min, 475 V(rms) typ and 525 V(rms) max when IFL=2.7 mA(rms); (3)FL Start Voltage (Ta=0°C): 1000 V(rms) min and 1600 V(rms) max; (4)High Level Input Voltage (VIH): 0.8 VDD min and VDD V max; (5)Low Level Input Voltage (VIL): 0 V min and 0.2 VDD V max; (6)IDD, Current Consumption: 240 mA typ; (7)IFL, Current Consumption:2.2 mA(rms) min, 2.7 mA(rms) typ and 5.0 mA(rms) max; (8)Power Consumption: 2.1W typ @70cd/m2.
Features
Features: (1)8.4”SVGA display size for notebook PC; (2)Slim(5.8mmMAX) & light weight(190gTYP) design.
