Product Summary
The IMT200-300-5 is a low cost full brick DC/DC converter. The device is targeted specifically at the telecommunication, industrial electronics, mobile telecommunication and distributed power markets. With a wide input voltage range of 200-400V the IMT200-300-5 is available with output voltage of either 3.3, 5, 12 or 15 Volts. The applications of the IMT200-300-5 include Telecommunications, Data Communications, Wireless Communications, Networking Gear, Servers, Switches and Data Storage, Semiconductor Test Equipment and Distributed Power Architecture.
Parametrics
IMT200-300-5 absolute maximum ratings: (1)Input voltage: 0 to 400V; (2)Operating case temperature: -25 to 100℃; (3)Storage temperature: -40 to 125℃; (4)Humidity: 95%.
Features
IMT200-300-5 features: (1)Delivers up to 200W in half brick; (2)No minimum load required; (3)Low profile of only 0.50 inch; (4)3.3V, 5V, 12V or 15V output models; (5)Wide input operating range 200-400V; (6)-40 to +100℃ ambient operation; (7)On/Off pin and remote sense; (8)Output adjustment +10% and -10% range; (9)1500V, 10M input-to-output isolation; (10)Meets Basic Insulation requirements of EN60950; (11)UL 1950 recognized, TUV EN60950 and CSA C22.2 No. 60950-00 Certified (pending); (12)Meets conducted limits of FCC Class B and CEI IEC61204-3 Class B with external filter; (13)MTBF of 1,000,000 hours @ 50℃ (Bellcore).
Diagrams
 |
